Product Description
The 42000 Liters Fuel Tanker Trailer is made of carbon steel.
It is mainly used to transport fuel,JET A-1, petrol, oil, diesel, gasoline, petroleum.
The fuel tanker’s tank size can range from 30000Liters to 60000Liters.
The fuel tank trailer’s compartment can be divided into 1~9 compartments according to customer’s need.
The fuel tank trailer’s suspension can be mechanical leaf spring suspension or airbag suspension, axles can be 3 and 4 axles, and tires can be single tire 385/65R22.5 or double tires 12R22.5 or 315/80R22.5 etc..
All our exported 42000 Liters Fuel Tanker Trailer for sale can be designed and customized for customer according to customer’s requirements. Strong structurer of the fuel tanker trailer is very suitable for African countries.
Specification:
Outer size(estimated): 11800*2500*3650mm
For transporting: Fuel, JET A-1, oil, diesel,petroleum, gasoline
Tank size: 42000Liters
Estimated weight: 9.6 ton
Main beam: Carbon steel
Tank’s Front/Rear end plate: Carbon steel,6mm thickness
Tank body : Carbon steel,5mm thickness
Compartment: 4 pieces
Manhole cover: Aluminium alloy manhole,4 pieces
Discharging valve: 3” API discharge valve, 4 pieces
Axle : 14ton axle, 3 pieces
Tire: 385/65R22.5,Single tires, 6 pieces
Suspension: Airbag suspension,front axle can be lifted up(mechanical leaf spring suspension is optional)
Kin pin: 50mm/90mm can be adjustable
Brake system: Standard double brake chamber
Landing gear : 28ton landing legs
Spare tire bracket :1 piece
Light : LED light
Voltage: 24v
Receptacle: 7 ways(7wire harness)
Tool box: 1 piece
Painting and logo: According to customer’s requirement
Advantage of BAPUTI 42000 liters fuel tanker trailer for sale:
1. The tank body is one -time forming,not only the production efficiency is improved, the
appearance is beautiful, and the product quality is fully guaranteed.The high quality welds
ensure no air leak,and with long service life .
2. High welding quality ensure the long service life of the fuel tanker trailer even under the most difficult road conditions.
3. With safety devices: the manhole is an explosion-proof large cover.
The bottom outlet of the tank is equipped with an emergency shut-off valve.
4. Water filled test for testing the sealing performance of tanker.
Features of BAPUTI 42000 liters Fuel Tanker Trailer for Sale:
Advanced design:
Finite element analysis method is adopted for the structure of the tank body and anti-wave plate, and the stress analysis model under all working conditions is established, and the lightweight design makes the strength and stiffness of the tank body better when the tank body is lighter;
Anti-shock structure:
The dish-shaped structure wave-proof board in the tank can effectively scatter shock waves around, reduce the local stress of the wave-proof board, and protect the tank body. According to the medium and road conditions, the anti-wave board adopts the method of dense and dense arrangement, and the force of the tank is more uniform;
Reinforcement ring structure:
The external reinforcement structure of the stainless steel tank is unique in China; the full-loading frame, the tank body bears most of the load, the weight of the whole vehicle is lighter, the tank body is not easily deformed, and it is more economical and safer.
Professional production:
advanced 13-meter automatic panel TIG welding machine, PLC programmable control technology, one-time canning forming process: reducing welding seams, high strength, smooth appearance, and stable vehicle performance;
Safety and environmental protection: A series of safety devices such as explosion-proof manhole, emergency cut-off bottom valve (subsea valve), breathing valve, tank top coaming, sealing wire harness, oil and gas recovery, etc., prevent rollover, collision, fire resistance, and improve loading efficiency at the same time. Safe and environmentally friendly.
The BAPUTI fuel tanker trailer for sale has a unique and beautiful appearance, and the structural parts are pretreated by sandblasting; the tank body is welded with a special tank body tooling fixture, which is welded with an automatic protection welding machine; the whole vehicle is reasonably matched, reliable in performance, and cost-effective High quality and stable quality, which can meet various different needs.
