Product Description
60 Ton Fence Cargo Trailer for Sale can be used to transport many kinds of objects, such as bags, boxes,animals,livestock and other bulk cargo. Its side boards and stakes can be opened, and it is more convenient to unload cargo. fence trailer is widely used by transportation companies in the logistics industry.
The fence semi trailer has 12 pieces of container twist locks, after dismantle the side boards and stakes from the trailer,it can transport 20ft and 40ft containers.
Side board and stake height can be customized according to customer's need.
Latest exported 40~60ton fence cargo semi trailer(short video):
Specification of Fence semi trailer stakes livestock transport truck trailer:
Loading Capacity: 60 tons
Axle: 3 pieces, 13T FUWA/BPW axle
Tyre: 12 pieces, 12R22.5
Dimensions(LxWxH): 12500mm x 3000 x 1550mm
Tare weight: 7ton
Suspension System: Leaf spring suspension / air suspension is optional
Brake System: Dual line pneumatic brake system with WABCO emergency relay valve
Main Beam: Height 500mm Q345
Chassis plate: upper 16mm, lower 18mm. Mid 10mm
Container Twist Locks: 12 pieces
Side Wall and Stake Height: 600mm; 800mm,1000mm,1500mm are optional
Kingpin: 2’ or 3.5’ interchangeable
Landing Gear: 28 Tons , Two speed manual operation
Electrical System: 1.Voltage: 24v 2. Receptacle: 7 ways (7 wire harness)
Lights and Reflectors: Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light
Tool Box: One tool box with a set of standard trailer tools
Spare Tyre Carrier: One piece or two pieces
Color: According to customer requirement
Features of BAPUTI Fence Semi Trailer:
1. Frame: The longitudinal beam made of hot-rolled section steel or welded manganese steel is welded with the through beam and section steel components to form a frame structure. Reasonable structure, balanced overall strength and stiffness, high bearing capacity, good elasticity without permanent deformation, light weight and large load capacity of the whole vehicle, the main beam is designed with equal section to achieve the best bearing effect.
2. Axles: Imported or domestic high-quality brand axles are selected, and ABS anti-lock braking systems of well-known brands at home and abroad are selected to improve the driving safety of the vehicle.
3. Suspension system: It adopts a unique new type of suspension system with high strength and strong impact resistance; the patented tie-rod fixing structure ensures that it will not loosen during frequent bumpy operation, effectively reducing tire wear and prolonging service life. Suspension and brake pads are thickened, and the hanging ribs are lengthened, which can effectively prevent cracking and welding. The brake valve uses the brand WABCO. The wires are waterproof wires. Applicable to all road conditions in Africa.
4. Braking system: a safe and reliable dual-circuit air-cut brake is used, a quick release valve is installed in the system, and the sub-pump is used to quickly return to the position when braking.
5. Sophisticated craftsmanship:
(1)The main parts of the vehicle are processed with advanced equipment, and the longitudinal beams are welded by a fully automatic tracking submerged arc welding machine. The assembly parts It adopts the process of painting first and then assembling.
(2)Automatic laser cutting machine: The who trailer parts are cut by laser cutting technology, with smooth and flat cutting surface,accurate cutting dimension, less welding stress and no deformation, and the outside of the whole vehicle parts is much more beautiful.
(3).Shot blasting machine: strengthen the beam to prevent the beam from breaking and peeling off paint.
6. Spray painting: electrophoresis primer + powder spray: This process is based on electrophoresis, through corona discharge, the topcoat powder is evenly attached to the body, and then melted at high temperature to form the topcoat. Durable against rust, support longer good looking and service life.
